One-to-One Laundry Dispenser Series
The One-to-One Modular Series is a compact dosing system purpose-built for space-restricted on-premise laundries. Its plug-and-play architecture lets you mix and match one to eight pump modules—maintenance-free diaphragm pumps, high-flow peristaltic pumps, or Venturi pumps—delivering the exact chemical-dosing capacity your operation requires.
One-to-One Laundry Dispenser Series
Modular Convenience for Seamless Washing
The One-to-One Modular Series is a compact dosing system purpose-built for space-restricted on-premise laundries. Its plug-and-play architecture lets you mix and match one to eight pump modules—maintenance-free diaphragm pumps, high-flow peristaltic pumps, or Venturi pumps—delivering the exact chemical-dosing capacity your operation requires.
One-to-One Modular Series
YDY-MKHF-6B IoT Modular Diaphragm Pump Laundry Chemicals Dispenser For One Washing Machine
NEWSPAPERS
Scope of Application
The YDY-MKHF-6B series is a maintenance-free dosing system purpose-built for a single washing machine. It can be configured with one to eight high-flow MWH-14 maintenance-free diaphragm pumps, offers enhanced pressure resistance, and is ideally suited for medium- to high-viscosity acidic or alkaline chemicals.
Hardware Features
-
Fitted with a patented, high-flow, maintenance-free diaphragm pump engineered specifically for acidic, alkaline, and viscous chemicals.
-
Features a modular architecture that allows any combination of 1 – 8 maintenance-free diaphragm or peristaltic pump modules.
-
Optional quick-connect rinse-manifold unit with rinse solenoid valve and wall-mount bracket for plug-and-play installation.
-
Built with a sealed, waterproof ABS industrial housing suitable for the high-temperature, high-humidity environment of commercial laundry facilities.
Software Features
-
Standard LCD color touchscreen provides one-touch access to status monitoring, program programming, alarms, and data summaries.
-
Optional SPLANEY remote IoT platform enables real-time wash-data monitoring and optimization of water and chemical consumption to lower operating costs.
-
Suports up to 27 programmable cycles with automatic, semi-automatic, and manual modes.
-
Holds ISO, CE, SGS certifications and more than 10 national patents.
-
Features a clean, minimalist design with the option to customize company logos to strengthen brand identity.
Pump Features
 MWH-14 Maintenance-free Square Diaphragm Pump
|
Data Visualization
IoT Remote Monitoring
IoT Remote Monitoring
Compact HD Color Touchscreen
The compact HD color touchscreen provides fast access to equipment status, parameter settings, and program creation/editing, while displaying intuitive production analytics for smarter wash management.
-
Real-time dashboards show consumption of chemicals and water and log each washer’s cycle steps, counts, and status.
-
Visual formula setup lets you enter chemical names, dosages, and unit prices with ease.
-
Intelligent fault diagnostics trigger on-screen alarms and maintenance recommendations.
SPLANEY Smart IoT System (Optional)
Utilizing the high-speed interactive features of the SPLANEY IoT system, users can remotely monitor the operational status and data of the system, and dynamically manage energy consumption through visual historical charts, significantly reducing on-site maintenance operations and improving work efficiency.
-
Wash count/weight
-
Chemical & water consumption/cost
-
Formula count/cost and share
-
Step count/usage
-
Liquid Level, water volume and system pressure
-
Wash data graphical display
信息为测试元素，使用时候可删除该元素放置自己想放的元素
这里是标题一h1占位文字
信息为测试元素，使用时候可删除该元素放置自己想放的元素
信息为测试元素，使用时候可删除该元素放置自己想放的元素
这里是占位文字
信息为测试元素，使用时候可删除该元素放置自己想放的元素
Accessories
WLA-800 smart low-level alarm system
The WLA-800 is an advanced chemical level monitoring device that alerts staff immediately with a buzzer or flashing light when chemicals are running low, ensuring uninterrupted workflow and improving efficiency and safety.
- Audio-visual warning system alerts low level and low battery in time to prevent unexpected failures
- Compatible with multi-band wireless mode, supports monitoring of up to 8 probes simultaneously for diverse applications
- Acid- and alkali-resistant casing and piping design ensures long-term stability
- Optional sensors available for remote monitoring of chemical usage
XLG-20 corrosion-resistant suction lance
The XLG-20 series corrosion-resistant suction lance is specially designed for chemical suction, featuring a built-in corrosion-resistant check valve and impurity filter to effectively prevent backflow and leakage, ensuring stable operation. Suitable for various conditions, it offers excellent corrosion resistance and safety.
-
Suction lance equipped with dedicated corrosion-resistant check valve and filter to prevent backflow and impurity intake
-
Made of highly corrosion-resistant materials, ensuring long-term stability and durability
-
Excellent airtightness, eliminating suction errors caused by leakage
XHH-50 series smart wide-voltage signal box
As the signal receiver for standard single-washer dispenser systems, the XHH-50 series signal box supports wide voltage input, seamlessly compatible with almost all washer control boards without the need to replace relays. It also features built-in short-circuit protection, ensuring long-term operational stability.
-
Supports DC/AC wide-voltage washer signal input, no need for relay replacement
-
Single Ethernet cable directly connects washer and dispenser, highly efficient installation
-
Built-in short-circuit protection ensures user safety
PFXZQ-120 series HD color formula selector
The formula selector allows users to manually choose washing programs via touchscreen or buttons. Unlike traditional systems, SPLANEY’s dispenser system can automatically match programming with standard single washers, giving users the option to use the formula selector freely.
-
Users can freely decide whether to use the formula selector
-
Manual chemical addition can be set via click to optimize washing results
-
Available in color LCD touchscreen and digital display versions
-
Formula information and washer number can be preset
